32055
Model features Pre-Order US$79 (due August 2019) - 25cm x 18cm - Relatively simple rigging - High quality Cartograf decals for 5 aircraft • 151 high quality injection moulded plastic parts • Optional side cowls, engine cowls, propellers, LePrieur rockets and Gnome engines • 2 highly detailed 28 part 80hp and 100hp Gnome engines • 9 photo-etched metal detail parts • Fine in scale rib tape detail • Full rigging diagrams

Sopwith’s wonderful Pup was developed from a design that their test pilot, Harry Hawker, legendarily chalked out on the factory floor for his own personal runabout in the latter stages of 1915. Featuring wing warping technology this runabout formed the basis for the Sopwith Sparrow of which only 4 were made. In February 1916 Sopwith took it upon themselves to produce a single seat fighter prototype based on this design, slightly redesigned, strengthened and with ailerons replacing wing warping for lateral control. Given the serial number 3691, this prototype attracted the attention of the Royal Naval Air Service (RNAS) who were suitably impressed enough to order the type into production as the Admiralty 9901 Type. The Royal Flying Corps (RFC) were likewise taken by the prototype with Maj. Gen. H.M. Trenchard famously stating ‘Let us get a squadron of these’ which lead to them ordering it into production as the Sopwith Scout. Despite being officially known as the Admiralty 9901 Type or Sopwith Scout it was quickly given the eminently more appropriate, albeit strictly unofficial, nickname ‘Pup’ after a remark by a Brig. Gen. W Sefton Brancker upon comparing it to the larger Sopwith 1 & ½ Strutter.



The Sopwith Pup was universally liked by the young aviators of the RNAS and RFC charged with flying it. More than 2100 Pups were built by The Sopwith Aviation Co Ltd, William Beardmore & Co Ltd, The Standard Motor Co Ltd and Whitehead Aircraft Ltd. Most Sopwith Pups were powered by a 80hp LeRhone 9c engine although many others with fitted with 80hp & 100hp Gnome (as included in this model) or Clerget engines. Ever adaptable, the Pup was modified for shipboard use by the RNAS as the 9901a Type, taking off from both aircraft carriers and platforms mounted on gun turrets. Despite having only one gun, its light weight and maneuverability ensured it was a good match for the twin gun armed Albatros D.II, Fokker D.II, Halberstadt DII and D.III fighters it faced in late 1916. At least 29 RFC and RNAS pilots achieved ace status in the Pup with victories claimed over the aforementioned fighters as well as the later Albatros D.IIIs and D.Vs, observation balloons, various two seaters, seaplanes and 5 Gotha bombers before being withdrawn from frontline service in the latter stages of 1917.



WW1 aircraft colours are contentious at the best of times and we have done our best to provide what we consider to be accurate painting information. Upper surface linen areas were doped in Protective Covering number 10 (PC10) or PC12. PC10 was made from mixes of yellow ochre, iron oxide and lamp black pigments and could vary between dark olive drab and chocolate brown depending on the mix and time spent exposed to the elements. PC12 is slightly less controversial although previous reports of it being red brown are in error and it was actually a dark chocolate brown. The undersides of the wings, tailplane and fuselage were left clear doped Irish linen, usually with a thin line along the leading finished with the same PC10 or PC12 as the upper surfaces. Metal cowling panels were often painted Battleship Grey on the exterior with the insides left unpainted, or left unpainted all together. Small metal fittings and brackets were usually black. All surfaces exhibited a shiny gloss appearance when new which would lose its shine and fade relatively quickly.
Wingspan:Length:Max Weight:Max Speed:
26’& 6” (8.07m)19’ & 3.75” (5.89m)1297lb (588.3kg) 100hp Gnome107mph (172kph) 100hp Gnome
No Manufactured:Production:Engine:Ceiling:
Approximately 2100 (includes over 280 rebuilds)Feb 1916 to April 1917(32055) 80hp Gnome & 100hp Gnome Monosoupape18500’ (5754m) 100hp Gnome
Armament:
.303 (7.7mm) Vickers gun and/or .303 (7.7mm) Lewis gun or 8 LePrieur rockets
References:
The Sopwith Pup, J.M Bruce, Gordon Page & Ray Sturtivant, Air Britain 2002 - Windsock Datafile Special Sopwith Pup , J.M Bruce 1992 - Windsock Datafile Sopwith Pup, J.M Bruce, 1986 - Osprey Sopwith Pup Aces of World War 1, Norman Franks, 2005 - 1914-18 Aviation Heritage Trust - Private Collections
