Model features

Released on 4 December 2017 (note that stock may arrive in some countries a week or two after this date) - 30cm x 21cm - High quality Cartograf decals for 5 aircraft - 144 high quality injection moulded plastic parts - Optional propellers, 20lb Cooper bombs & carrier, Holt flares & lights and Lewis gun armament - Optional early and late production radiators, centre sections, tail skids and front cowls - Highly detailed 18 part 200hp Hispano-Suiza engine (originally available in 32003 1/32 SE.5a “Hisso”) - 12 photo-etched detail parts - Fine in scale rib tape detail - Full rigging diagram.

The Sopwith 5F.1 Dolphin was designed during the 2nd quarter of 1917 to make use of the promising new 200hp Hispano-Suiza V8 geared “Hisso” engine which was also to power the SPAD XIII and SE.5a. One other overriding consideration was to overcome the staggeringly poor visibility caused by the top wing centre section of the otherwise quite remarkable Sopwith Camel. The initial Dolphin prototype 5F.1/1 rolled out in May 1917 and featured wide twin bay wings with negative stagger, a completely open top wing centre section, unbalanced Camel style rudder & fin and wooden undercarriage Vee struts. The very deep fuselage occupied the full height of the wing gap and featured a tall radiator in front of the engine. It"s first flight was delayed due to problems securing a suitable example of the engine. The 2nd prototype 5F.1/2 appeared in late July and incorporated numerous improvements including a balanced rudder, cutouts in the bottom wings, removing the frontal radiator (which allowed the streamlining of the nose) and replacing it with twin radiators mounted in the top wings. These radiators proved ineffective so were in turn replaced by versions mounted on the sides of the fuselage. The cutouts in the bottom wings were deleted for prototypes 5F.1/3 & 5F.1/4 which appeared during October and introduced a more substantial fin, lowered rear decking and twin upwards firing Lewis guns.


It was pretty much in this form that the initial production Dolphins were delivered in late November 1917, except they had reduced negative wing stagger and steel tube undercarriage Vee struts. The twin Lewis guns proved heavy and cumbersome so the port gun was quickly deleted, and frequently the starboard gun was removed in service. Early production Sopwith 5F.1 Dolphins featured a Birch plywood tail skid, 4” radiators and vertical neck padding on the centre section. There were several attempts to provide “roll over” protection for the pilot"s exposed head but none were adopted, although some late production aircraft featured a quick release for the port cockpit rigging to allow the pilot to escape from an upturned aircraft. Other improvements incorporated on late production aircraft included a steel tube tail skid, 8” radiators and a centre section with improved Aldis sight mounts and more streamlined padding.


Supply and reliability problems with the 200hp Hispano-Suiza V8 geared “Hisso” engine would continue to plague the Dolphin for most of it"s service (as they did for the SE.5a “Hisso”) but eventually it became well regarded as a high altitude fighter. The Sopwith 5F.1 Dolphin II was developed for the French in mid 1918 to utilize a 300hp direct drive Hispano-Suiza engine and the USAS ordered over 2000 to be built by SACA in France but the Armistice was signed before any were delivered and the order was canceled. The Sopwith 5F.1 Dolphin III was under development shortly before the Armistice and was to utilize the more reliable direct drive “Viper” version of the 200hp Hispano-Suiza. Only a handful of Dolphin II and III were produced and can be identified by their lower propeller thrust line and fully cowled Vickers guns. Nearly 1800 Dolphins were built by The Sopwith Aviation Company LTD, Hooper & Company LTD and The Darracq Motor Engineering Company LTD. The Sopwith 5F.1 Dolphin was officially declared obsolete by the RAF in September 1921 but a small number continued to see service with Poland.


WW1 aircraft colours are contentious at the best of times and we have done our best to provide what we consider to be accurate painting information. Sopwith"s “General Arrangement of Fuselage Fabric” drawing specifies that the fabric is “...to receive 5 coats of Cellon Dope & 2 coats of P.G(sic) No.10 Pigment known as "Cellon" Scheme A”. PC10 was made from mixes of yellow ochre, iron oxide and lamp black pigments and could vary between olive drab and chocolate brown depending on the mix and time spent exposed to the elements. The undersides of the wings, tailplane and fuselage were left clear doped Irish linen. Wooden fuselage panels, metal cowlings and struts were painted a dark battleship grey although some were clearly painted in a darker colour roughly matching the PC10 dope of the fabric areas. Metal brackets and fittings were usually battleship grey. All fabric surfaces exhibited a gloss appearance when new which would lose its shine relatively quickly in service.


Wingspan:Length:Max Weight:Max Speed:
32.5ft (9.90m)22.25ft (6.78m) 2008 lb (911kg) 128mph (206kph)
No Manufactured:Production:Engine:Ceiling:
(all types) 1779June 1917 to July 1919200hp Hispano-Suiza geared V8+21000ft (6400m)
Armament:
2x .303 (7.7mm) Vickers Mk.1*, up to 2x .303 (7.7mm) Lewis guns and 100 lb (45kg) of bombs
References:
Windsock Datafile 54 Sopwith Dolphin, J.M Bruce, 1995 - Sopwith Aviation Co Ltd drawings - The Sopwith Dolphin in RFC, RNAS, RAF & Polish Service, Cross & Cockade International 2012 - Technical Notes Sopwith Dolphin 5F.1, Royal Air Force 1918 - Flugsport Vol.XI #3, 5 February 1919 – Sopwith Dolphin and Snipe Aces of World War 1, Norman Franks, Osprey 2002 - 1914-18 Aviation Heritage Trust – The Vintage Aviator LTD – Colin Owers - Private Collections
