32028
Model features

Released in October 2012 - Sold out on 7 August 2016 - 26cm x 24cm - High quality Cartograf decals for 5 aircraft - 166 high quality injection moulded plastic parts - 6 photo-etched metal detail parts - Highly detailed 17 part 100hp Gnome Monosoupape engine - Optional 2 & 4 blade propellers, instrument boards, undercarriage, aileron controls and ammunition stowage - Fine in scale rib tape detail - full rigging diagrams


The prototype AMC DH.2 (Aircraft Manufacturing Company de Havilland 2) first flew in June 1915 and was sent to the front for evaluation in late July where it was promptly captured by the Germans in early August. Undeterred by this not insignificant setback, development continued and full scale production began in November. This allowed 24 Sqn to be fully equipped with the DH.2 when they arrived in France during February 1916 where they, along with squadrons equipped with the FE.2b and French Nieuport 11, began putting an end to the 6 month long “Fokker scourge”. Although powered by essentially the same engine as the Fokker E.II & E.III the DH.2 was designed from the outset with maneuverability in mind and the wing warping Eindeckers proved no match in combat. It would take until July-August 1916 before the twin lMG 08 ‘Spandau’ armed Halberstadt, Fokker and Albatros D type biplanes would regain air supremacy for the Germans. By June-July 1917 the DH.2 had been replaced in front line service by the Nieuport 17 and DH.5, although they continued to serve in the Middle East well into 1918.


Early production DH.2 arrived with an impracticable flexible ‘wobbly’ Lewis gun mount, 2 bladed propeller, bungee or spring type aileron returns and had the 5 gallon emergency fuel tank fixed under the top wing center section. Other identifying features of early production aircraft are the small fairings at the rear of the nacelle, external magazine storage for 4x 47 round magazines, a single tube pitot head and the rudder control cable pulleys positioned slightly further forward in the nacelle. Like all new aircraft many unofficial and official changes would take place in service, some of which are noted here; the position of the emergency petrol tank directly above the hot engine was not thought to be ideal so it migrated to various positions on the top wing. Problems with the bottom longerons cracking lead to small inspection flaps being added just above the front undercarriage strut, the ‘wobbly’ Lewis gun mount was fixed to fire straight ahead and the capacity of the main petrol tank was increased. The instrument board layout could vary considerably as did, surprisingly, the front cowl. A 4 bladed propeller developed for another single seat pusher, the FE.8, was introduced in the middle of 1916 and improved performance.

Wingspan:Length:Max Weight:Max Speed:
28.25 ft (8.61m)25.2ft (7.683m)1441lb (653.8kg)94mph (150kph)
No Manufactured:Production:Engine:Ceiling:
450 approximatelySept 1915 - Late 1916100hp Gnome Monosoupape14000ft (4270m)
Armament:
0.303in (7.7mm) Lewis Mk.II machine gun
References:
The AMC DH.2 Windsock Datafile 48, BJ Gray, 1994 - WW1 Aero #146 1994 - Cross & Cockade International Journal V20#1 1989 - The Vintage Aviator Ltd - 1914-18 Aviation Heritage Trust - Colin Owers - Private Collections
